Mirrorless

Nikon Z-mount

FX

CMOS, 35.9 mm x 23.9 mm

25.28 million

Image sensor cleaning, image dust off reference data (Capture NX-D software required)

24.5 million

[FX (36 x 24)] selected for image area: (L) 6048 x 4024 (24.3 million), (M) 4528 x 3016 (13.7 million), (S) 3024 x 2016 (6.1 million), [DX (24 x 16)] selected for image area: (L) 3936 x 2624 (10.3 million), (M) 2944 x 1968 (5.8 million), (S) 1968 x 1312 (2.6 million), [1:1 (24 x 24)] selected for image area: (L) 4016 x 4016 (16.1 million), (M) 3008 x 3008 (9 million), (S) 2000 x 2000 (4 million), [16:9 (36 x 20)] selected for image area: (L) 6048 x 3400 (20.6 million), (M) 4528 x 2544 (11.5 million), (S) 3024 x 1696 (5.1 million), photos captured during movie recording at frame size of 3840 x 2160: 3840 x 2160, photos captured during movie recording at frame size of: 1920 x 1080

NEF (RAW): 12 or 14 bit (lossless compressed, compressed, or uncompressed); large, medium, and small (medium and small images are recorded at a bit depth of 12 bits using lossless compression) available, JPEG: JPEG-Baseline compliant with Fine (approx. 1:4), Normal (approx. 1:8), or Basic (approx. 1:16) compression; Quality priority available, NEF (RAW)+JPEG: Single photo recorded in both NEF (RAW) and JPEG formats

Auto, Standard, Neutral, Vivid, Monochrome, Portrait, Landscape, Flat, Creative Picture Control (Dream, Morning, Pop, Sunday, Somber, Dramatic, Silence, Bleached, Melancholic, Pure, Denim, Toy, Sepia, Blue, Red, Pink, Charcoal, Graphite, Binary, Carbon); selected Picture Control can be modified; storage for custom Picture Controls

CFexpress (Type B), XQD, SD, SDHC (UHS-II compliant), SDXC (UHS-II compliant)

1 CFexpress or XQD card and 1 Secure Digital (SD) card; each card can be used for overflow storage and backup storage or for separate storage of NEF (RAW) and JPEG images; images can be copied between cards.

DCF 2.0, Exif 2.31

1.27 cm approx. 3690k-dot (Quad VGA) OLED electronic viewfinder with color balance and 11-level auto and manual brightness controls

Approx. 100% horizontal and vertical

Approx. 0.8x (50 mm lens at infinity, -1.0 m⁻¹)

21 mm (-1.0 m⁻¹; from center surface of viewfinder eyepiece lens)

-4 to +2 m⁻¹

Automatic switching between monitor and viewfinder display

NIKKOR Z-mount lenses, NIKKOR F-mount lenses (bayonet adapter required; limitations may apply)

Electronically-controlled vertical-travel focal-plane mechanical shutter; electronic front-curtain shutter; electronic shutter

1/8000 to 30 sec., (choose from 1/3 and 1/2 EV steps, extendable to 900 sec. in M mode); Bulb, Time, X200

X=1/200 sec.; shutter synchronized at 1/200 sec. or slower; Auto FP High-Speed Sync supported

S (single frame), CL (continuous low speed), CH (continuous high speed), continuous H (extended), self-timer

Up to 14 fps, Low speed: approx. 1 to 5 fps, High speed: approx. 5.5 fps, High speed (extended): Approx. 14 fps (14-bit NEF/RAW: approx. 10 fps)

2 sec., 5 sec., 10 sec., 20 sec.; 1 to 9 exposures at intervals of 0.5, 1, 2, or 3 sec.

TTL exposure metering using camera image sensor

Center-weighted and matrix metering: 75% of sensitivity concentrated on a 12 mm circle in the center of the frame; sensitivity can, conversely, be based on spot metering of the entire frame: Metering performed in a 4 mm circle (approx. 1.5% of the frame) in the center of the AF point highlight-weighted metering

-4 to +17 EV

Auto, P: programmed auto with flexible program; S: shutter-priority auto; A: aperture-priority auto; M: manual; U1, U2, and U3: user settings modes

-5 to +5 EV, in increments of 1/3 or 1/2 EV, available in P, S, A, and M modes

Luminosity locked at detected value

ISO 100 to 51200 in 1/3 or 1/2 EV steps, can also be set to approx. 0.3, 0.5, 0.7, or 1 EV (ISO 50 equivalent) below ISO 100 or to approx. 0.3, 0.5, 0.7, 1, or 2 EV (ISO 204800 equivalent) above ISO 51200; auto ISO sensitivity control available (recommended exposure index)

Auto, Extra high, High, Normal, Low, and Off

Add, average, lighten, and darken

HDR (High Dynamic Range), flicker reduction in photo mode

Hybrid phase-detection/contrast-detect AF with AF illuminator

-4.5 to +19 EV (-6 to +19 EV with low-light AF)

Single-servo AF (AF-S), continuous-servo AF (AF-C), full-time AF (AF-F; only available in movie mode); predictive focus tracking; manual focus (M)

273

Pinpoint AF (only available in photo mode), single-point AF, and dynamic-area AF (only available in photo mode); wide-area AF (S); wide-area AF (L); wide-area AF (L-people); wide-area AF (L-animals); auto-area AF; auto-area AF (people); auto-area AF (animals)

Focus can be locked by pressing the shutter-release button halfway (single-servo AF/AF-S) or the center of the sub-selector

5-axis image sensor shift

Optical shift (available with VR lenses)

TTL: i-TTL flash control; i-TTL balanced fill-flash is used with matrix, center-weighted, and highlight-weighted metering, standard i-TTL fill-flash with spot metering

Front-curtain sync, slow sync, rear-curtain sync, red-eye reduction, red-eye reduction with slow sync, off

-3 to +1 EV, in 1/3 or 1/2 EV steps, available in P, S, A, and M modes

Lights when external flash unit is fully charged, and flashes as a warning of underexposure after flash fires at full output

ISO 518 hot-shoe with sync and data contacts and safety lock

i-TTL flash control, radio-controlled Advanced Wireless Lighting, optical Advanced Wireless Lighting, modeling illumination, FV lock, Color Information Communication, Auto FP High-Speed Sync, unified flash control

Auto (3 types), natural light auto, direct sunlight, cloudy, shade, incandescent, fluorescent (7 types), flash, choose color temperature (2500 to 10000 K), preset manual (up to 6 values can be stored), all with fine-tuning except choose color temperature

Exposure and/or flash, white balance, and ADL

TTL exposure metering with main image sensor, TTL exposure metering with camera image sensor

Matrix, center-weighted, or highlight-weighted
