Mirrorless

Nikon Z mount

DX, CMOS, 23.5 mm x 15.7 mm

21.51 million

Image Dust Off reference data (NX Studio software required)

20.9 million

[DX (24x16)] selected for image area: (L)5568 x 3712 (20.7 million), (M)4176 x 2784 (11.6 million), (S)2784 x 1856 (5.2 million), [1:1 (16x16)] selected for image area: (L)3712 x 3712 (13.8 million), (M)2784 x 2784 (7.8 million), (S)1856 x 1856 (3.4 million), [16:9 (24x14)] selected for image area: (L)5568 x 3128 (17.4 million), (M)4176 x 2344 (9.8 million), (S)2784 x 1560 (4.3 million), photos taken during movie recording with frame size of 3840 x 2160: 3840 x 2160, photos taken during movie recording with frame size of: 1920 x 1080

NEF (RAW): 12 or 14-bit, JPEG: JPEG-Baseline compliant with Fine (approx. 1:4), Normal (approx. 1:8) or Basic (approx. 1:16) compression, NEF (RAW)+JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats

Auto, Standard, Neutral, Vivid, Monochrome, Portrait, Landscape, Flat, Creative Picture Controls (Dream, Morning, Pop, Sunday, Somber, Dramatic, Silence, Bleached, Melancholic, Pure, Denim, Toy, Sepia, Blue, Red, Pink, Charcoal, Graphite, Binary, Black); selected Picture Control can be modified; storage for custom Picture Controls

SD, SDHC (UHS-I compliant), SDXC (UHS-I compliant)

1 Secure Digital (SD) card

DCF 2.0, Exif 2.31

1.0 cm (0.39 in.) approx. 2360k-dot (XGA) OLED electronic viewfinder with color balance and auto and 7-level manual brightness controls

Approx. 100% horizontal and 100% vertical

Approx. 1.02x (50 mm lens at infinity, –1.0 m⁻¹)

19.5 mm (–1.0 m⁻¹; from center surface of eyepiece lens)

-3 to +3 m⁻¹

Automatically switches between monitor and viewfinder displays

NIKKOR lenses with Z mount, NIKKOR lenses with F mount (mount adapter required; limitations may apply)

Electronically-controlled vertical-travel focal-plane mechanical shutter; electronic front-curtain shutter; electronic shutter

Using shutter speed dial: 1/4000 to 4 s (1 step), Bulb, Time (flash sync) Using main command dial: 1/4000 to 30 s (1/3 step, can be extended to 900 s in M mode), Bulb, Time (flash sync)

X = 1/200 s; synchronizes with shutter at 1/200 s or slower; auto FP high-speed sync supported

S (single frame), CL (continuous low speed), CH (continuous high speed), Continuous H (extended), Self-timer

Up to 11 fps, Low speed: 1 to 4 fps approx., High speed: 5 fps approx., High speed (extended): Approx. 11 fps

2 s, 5 s, 10 s, 20 s; 1 to 9 exposures at intervals of 0.5, 1, 2, or 3 s

TTL exposure metering using camera image sensor

Matrix, center-weighted: 75% of sensitivity concentrated on an 8 mm circle in the center of the frame; sensitivity can instead be based on the average of the entire frame, spot metering: Metering in a 3.5 mm circle (about 2.5% of the frame) centered on the selected AF-area, highlight-weighted metering

-4 to +17 EV

Auto P: programmed auto with flexible program; S: shutter-priority auto; A: aperture-priority auto; M: manual

Range: -3 to +3 EV (when exposure compensation dial is set to [c]), Increment: 1/3 step

Luminosity locked at detected value

ISO 100 to 51200 in steps of 1/3 EV, can also be set to approx. 1 EV above ISO 51200 (ISO 102400 equivalent) or to approx. 2 EV above ISO 51200 (ISO 204800 equivalent); auto ISO sensitivity control available (recommended exposure index)

Auto, Extra high, High, Normal, Low, and Off

Add, average, lighten, darken

HDR (High Dynamic Range), flicker reduction (light flickering) in photo mode

Hybrid phase-detection/contrast-detect AF with AF illuminator

-4.5 to +19 EV 3, with low-light AF: -3 to +19 EV

Single-servo AF (AF-S), continuous-servo AF (AF-C), auto AF-area mode selector (AF-A; only available in photo mode), full-time AF (AF-F; only available in video standard), predictive focus tracking; manual focus (M): Electronic rangefinder can be used

209

Pinpoint AF (only available in photo mode), single-point AF, dynamic-area AF (only available in photo mode); wide-area AF (S), wide-area AF (L), wide-area AF (L-people), wide-area AF (L-animals); auto-area AF, auto-area AF (people); auto-area AF (animals)

Press AE-L/AF-L button or press shutter release button halfway (single-servo AF/AF-S)

TTL: i-TTL flash control; i-TTL balanced fill-flash used with matrix, center-weighted, and highlight-weighted metering, standard i-TTL fill-flash with spot metering

Front-curtain sync, slow sync, rear-curtain sync, red-eye reduction, red-eye reduction with slow sync, off

-3 to +1 EV, in steps of 1/3 EV, available in P, S, A, and M modes

Lights when optional flash unit is fully charged; blinks as underexposure warning after flash is fired at full output

ISO 518 hot-shoe with sync and data contacts and safety lock

i-TTL flash control, Advanced Wireless Lighting (optical), FV lock, color information communication, auto FP high-speed sync

Auto (3 types), natural light auto, direct sunlight, cloudy, shade, incandescent, fluorescent (3 types), flash, choose color temperature (2500 to 10000 K), preset manual (up to 6 values can be stored), all with fine tuning except choose color temperature

Exposure and/or flash, white balance, and ADL

TTL exposure metering using main image sensor, TTL exposure metering using camera image sensor

Matrix, center-weighted, or highlight-weighted

3840 x 2160 (4K UHD): 30p (progressive)/25p/24p, 1920 x 1080: 120p/100p/60p/50p/30p/25p/24p, 1920 x 1080 (slow-motion): 30p (x4)/25p (x4)/24p (x5)

MOV, MP4

H.264/MPEG-4 Advanced Video Coding

Linear PCM (for videos recorded in MOV format), AAC (for videos recorded in MP4 format)

Built-in stereo or external microphone with attenuator option; sensitivity adjustable

M: manual selection (ISO 100-25600; 1/3 EV step format); auto ISO sensitivity control (ISO 100 to 25600) available with selectable upper limit P, S, A: auto ISO sensitivity control (ISO 100 to 25600) with limit
